Lithium Battery Module

150AH Lithium Battery Module

● High energy density: the same weight or volume, lithium battery modules can store more energy;
● Long cycle life: after multiple charge and discharge cycles, the performance attenuation is small, reducing the cost of use;
● High safety: multi-layer safety protection design, including over-charge, over-discharge, over-temperature, short circuit and other protection functions, effectively prevent safety hazards;
● High consistency: the battery cells in the lithium battery module are strictly screened and matched, with high capacity, internal resistance, voltage, discharge curve and other consistency, to ensure stability and reliability;
● Customizability: Lithium battery modules can be customized according to different application scenarios and needs, including voltage, capacity, shape and other aspects of customization to meet the specific needs of customers;

  • Battery System:

    Customized 1

  • Battery Dimensions:

    Customized 2

  • Battesy Weight:

    Customized 3

  • Adaptation type:

    Customized 4

150AH Lithium Battery Module

Contact Us
150模组拆解素材
电芯模组通用素材 拷贝
  Detailed parameters (support customization)
Specifications
1P8S
2P4S
1P10S
Model
25.6V-150AH
12.8V-300AH
32V-150AH
Capacity (AH)
150AH
300AH
150AH
Dimensions(mm)
(311*202*219)±2
(311*202*219)±2
(378*202*219)±2
Nominal voltage (V)
25.6V
12.8V
32V
Weight(KG)
24.6±1KG
24.6±1KG
30.6±1KG
Standard charging current (A)
≤0.5C(shall not exceed 200 at most)
Peak current (A)
1C 20S
Operating temperature range (°C)
-20--55(Charging requires temperatures above 0°C.)
Cycle life (cycles)
80%DOD≥3000 times
