Lithium Battery Module
206AH Lithium Battery Module
● High energy density: the same weight or volume, lithium battery modules can store more energy;
● Long cycle life: after multiple charge and discharge cycles, the performance attenuation is small, reducing the cost of use;
● High safety: multi-layer safety protection design, including over-charge, over-discharge, over-temperature, short circuit and other protection functions, effectively prevent safety hazards;
● High consistency: the battery cells in the lithium battery module are strictly screened and matched, with high capacity, internal resistance, voltage, discharge curve and other consistency, to ensure stability and reliability;
● Customizability: Lithium battery modules can be customized according to different application scenarios and needs, including voltage, capacity, shape and other aspects of customization to meet the specific needs of customers;
-
Battery System:
Customized 1
-
Battery Dimensions:
Customized 2
-
Battesy Weight:
Customized 3
-
Adaptation type：
Customized 4
| Detailed parameters (support customization) | |||
|---|---|---|---|
Specifications |
1P8S |
2P4S |
1P10S |
Model |
25.6V-206AH |
12.8V-412AH |
32V-206AH |
Capacity (AH) |
206AH |
412AH |
206AH |
Dimensions（mm) |
（311*202*219）±2 |
（311*202*219）±2 |
（378*202*219）±2 |
| Nominal voltage (V) | 25.6V |
12.8V |
32V |
Weight（KG） |
34.5±1KG |
34.5±1KG |
42.6±1KG |
Standard charging current (A) |
≤0.5C(shall not exceed 200 at most) |
||
Peak current (A) |
1C 20S |
||
Operating temperature range (°C) |
-20--55(Charging requires temperatures above 0°C.） |
||
Cycle life (cycles) |
80%DOD≥3000 times |
||
